Based on the KS Q 9100
System, the international quality
standard for the aircraft business,
we strive for reliable quality
management by applying the
latest measuring equipment and
continuous quality training
activities with skilled quality
personnel.
CMM (Coordinate Measuring Machine)
 |
Specifications of DELTA Slant | |
|---|---|---|
| MODEL | Hexagon Delta | |
| Measuring Range (mm) | X : 3,000 Y : 8,000 Z : 2,000 |
|
| Positioning repeatability (μm ) | 035μm | |
| Max, 3DPositioning Speed (mm/s) | 666 mm/s | |
| Max, Part weight (ton) | 24 ton | |
 |
Specifications of DELTA Slant | |
|---|---|---|
| MODEL | Hexagon Delta | |
| Measuring Range (mm) | X : 1,500 Y : 3,000 Z : 1,000 |
|
| Positioning repeatability (μm ) | 035μm | |
| Max, 3DPositioning Speed (mm/s) | 200 mm/s | |
| Max, Part weight (ton) | 3 ton | |
Laser Tracker
 |
Specifications of Laser Absolute Tracker AT901 - Long Range | |
|---|---|---|
| MODEL | Leica | |
| Abosolute interferometer | yes | |
| Typical measurement volume | 160m | |
| Compatible with T-Prducts | yes | |
| Max, measurement volume | 30m | |
