DISTANCE ( X Y Z A B) (X) 8250mm (Y) 5000mm (Z) 1000mm

MAX RPM 15,000 r/min

OUTPUT 34 / 45.9 Kw

TORQUE 108.2 / 146.1 Nm

DISTANCE ( X Y Z) (X) 8250mm (Y) 3500mm (Z) 1100mm

MAX RPM 30,000 r/min

OUTPUT 55 / 37 Kw

TORQUE 1009 Nm

DISTANCE ( X Y Z A B)(X) 1000mm (Y) 900mm (Z) 685mm

MAX RPM 10,000 r/min

OUTPUT 32 / 18.5 Kw

TORQUE 204 Nm

DISTANCE ( X Y Z A B)(X) 2100mm (Y) 1350mm (Z) 1400mm

MAX RPM 8,000 r/min

OUTPUT 26 / 22 Kw

TORQUE 807 / 686 Nm

DISTANCE ( X Y Z )(X) 2470 mm (Y) 1000 mm (Z) 750 mm

MOTOR POWER 2.2 Kw

USERFULL LENGTH 1050 mm

BENDING CAPACITY 5 m

DISTANCE ( X Y Z )(X) 2500 mm (Y) 1000 mm (Z) 2400 mm

MOTOR POWER 7.5 Kw

PRESS POWER 1000 kN

MAX PRESSURE 263 bar

DISTANCE ( X Y Z )(X) 1050mm (Y) 830 mm (Z) 2300mm

PRESS POWER 50 ton

FRAME STYLE 4 POST

FORMABLE SIZE (X) 508 mm (Y)914.4 mm (Z) 88.9 mm

DISTANCE ( X Y Z )(X) 1250mm (Y) 3100 mm (Z) 2600mm

MOTER POWER 7.5 Kw

PRESS POWER 100 ton

WORKING LENGTH 4.5t X 1800mm

MODELLeica

Abosolute interferometer YES

Compatible with T-Prducts YES

Measurement volume30m ~ 160m

DISTANCE ( X Y Z )(X) 3000mm (Y) 8000mm (Z) 2000mm

Positioning repeatability 035μm

3DPositioning Speed Max 666 mm/s

Max, Part weight 24 ton

DISTANCE ( X Y Z )(X) 1000mm (Y) 3700mm (Z) 3400mm

TYPE KR-2400

SPEC Drivmatic Rivter

DISTANCE ( X Y Z )(X) 1200mm (Y) 2800mm (Z) 2300mm

TYPE PMCO. 25STM

SPEC R/S/W

DISTANCE ( L W H )(L) 11,700mm (W) 4200mm (H) 4000mm
